RB标准型
| 公称型号(按密封形式区分) | 主要尺寸(mm) | 滚柱节圆直径 | 额定载荷(KN) | 润滑孔 | 更多操作 | ||||||
| 开式 | 密封型 | d | D | B | r1(min) | dp | Cr | Cor | a | b | |
| RB2008 | RB2008UU | 20 | 36 | 8 | 0.5 | 27 | 1.62 | 1.55 | 2 | 0.8 | 咨询客服 |
| RB2508 | RB2508UU | 25 | 41 | 8 | 0.5 | 32 | 1.82 | 1.92 | 2 | 0.8 | 咨询客服 |
| RB3010 | RB3010UU | 30 | 55 | 10 | 0.6 | 41.5 | 3.83 | 4.13 | 2.5 | 1 | 咨询客服 |
| RB3510 | RB3510UU | 35 | 60 | 10 | 0.6 | 46.5 | 3.82 | 4.56 | 2.5 | 1 | 咨询客服 |
| RB4010 | RB4010UU | 40 | 65 | 10 | 0.6 | 51.5 | 4.28 | 5.14 | 2.5 | 1 | 咨询客服 |
| RB4510 | RB4510UU | 45 | 70 | 10 | 0.6 | 56.5 | 4.31 | 5.65 | 2.5 | 1 | 咨询客服 |
| RB5013 | RB5013UU | 50 | 80 | 13 | 0.6 | 64 | 10.7 | 12.6 | 2.5 | 1.6 | 咨询客服 |
| RB6013 | RB6013UU | 60 | 90 | 13 | 0.6 | 74 | 11.6 | 14.6 | 2.5 | 1.6 | 咨询客服 |
| RB7010 | RB7010UU | 70 | 90 | 10 | 0.6 | 80 | 11.2 | 14.1 | 2.5 | 1 | 咨询客服 |
| RB7013 | RB7013UU | 70 | 100 | 13 | 0.6 | 84 | 12.3 | 16.7 | 2.5 | 1.6 | 咨询客服 |
| RB8016 | RB8016UU | 80 | 120 | 16 | 0.6 | 98 | 18.6 | 25.5 | 3 | 1.6 | 咨询客服 |
| RB9013 | RB9013UU | 90 | 115 | 13 | 1 | 102 | 14.2 | 19.9 | 2.5 | 1.6 | 咨询客服 |
| RB9016 | RB9016UU | 90 | 130 | 16 | 1 | 108 | 19.4 | 28.6 | 3 | 1.6 | 咨询客服 |
| RB10013 | RB10013UU | 100 | 125 | 13 | 1 | 112 | 17.6 | 23.8 | 2.5 | 1.6 | 咨询客服 |
| RB10016 | RB10016UU | 100 | 140 | 16 | 1 | 119.3 | 28.6 | 43.8 | 3.5 | 1.6 | 咨询客服 |
