产品分类
公制TDI型
| 公称型号(公制双列) | 主要尺寸(mm) | 额定载荷(KN) | 疲劳极限载荷(KN) | 更多操作 | ||||||
| TDI整体内圈型 | d | D | T | C | r(min) | r1(min) | Cr | Cor | Cu | |
| T45320D | 100 | 165 | 52 | 52 | 2 | 2.5 | 298 | 384 | 55.9 | 咨询客服 |
| T45322D | 110 | 180 | 56 | 56 | 2 | 2.5 | 378 | 505 | 72.2 | 咨询客服 |
| T45224D | 120 | 180 | 46 | 46 | 2 | 2.5 | 286 | 424 | 59.4 | 咨询客服 |
| T45324D | 120 | 200 | 62 | 62 | 2 | 2.5 | 444 | 598 | 83.4 | 咨询客服 |
| T45226D | 130 | 200 | 52 | 52 | 2 | 2.5 | 376 | 548 | 75.6 | 咨询客服 |
| T45326D | 130 | 210 | 64 | 64 | 2 | 2.5 | 476 | 657 | 90.3 | 咨询客服 |
| T45228D | 140 | 210 | 53 | 53 | 2 | 2.5 | 390 | 564 | 76.9 | 咨询客服 |
| T45328D | 140 | 225 | 68 | 68 | 2.5 | 3 | 611 | 807 | 103 | 咨询客服 |
| T45230D | 150 | 225 | 56 | 56 | 2.5 | 3 | 445 | 686 | 91.6 | 咨询客服 |
| T45330D | 150 | 250 | 80 | 80 | 2.5 | 3 | 684 | 955 | 120 | 咨询客服 |
| T45232D | 160 | 240 | 60 | 60 | 2.5 | 3 | 488 | 705 | 93.1 | 咨询客服 |
| T45332D | 160 | 270 | 86 | 86 | 2.5 | 3 | 832 | 1100 | 146 | 咨询客服 |
| T45234D | 170 | 260 | 67 | 67 | 2.5 | 3 | 654 | 956 | 124 | 咨询客服 |
| T45334D | 170 | 280 | 88 | 88 | 2.5 | 3 | 834 | 1210 | 145 | 咨询客服 |
| T45236D | 180 | 280 | 74 | 74 | 2.5 | 3 | 722 | 1050 | 125 | 咨询客服 |
