NAG型
| 公称型号(NAG49满装系列) | 主要尺寸(mm) | 额定载荷(KN) | 更多操作 | ||||||||
| 开式 | 密封型 | d | D | B | rs(min) | J | Ew(开式) | Ew(密封型) | Cr | Cor | |
| NAG4900 | NAG4900UU | 10 | 22 | 13 | 0.3 | 15.5 | 18.5 | 19.5 | 9.65 | 10.8 | 咨询客服 |
| NAG4901 | NAG4901UU | 12 | 24 | 13 | 0.3 | 17 | 20 | 21 | 10.3 | 12 | 咨询客服 |
| NAG4902 | NAG4902UU | 15 | 28 | 13 | 0.3 | 21 | 24 | 25 | 11.8 | 15.2 | 咨询客服 |
| NAG4903 | NAG4903UU | 17 | 30 | 13 | 0.3 | 22.5 | 25.5 | 26.5 | 12.3 | 16.5 | 咨询客服 |
| NAG4904 | NAG4904UU | 20 | 37 | 17 | 0.3 | 24 | 31.5 | 31.5 | 15.6 | 18.9 | 咨询客服 |
| NAG4905 | NAG4905UU | 25 | 42 | 17 | 0.3 | 29.5 | 37 | 37 | 17.5 | 23.2 | 咨询客服 |
| NAG4906 | NAG4906UU | 30 | 47 | 17 | 0.3 | 34 | 41.5 | 41.5 | 19.4 | 27.6 | 咨询客服 |
| NAG4907 | NAG4907UU | 35 | 55 | 20 | 0.6 | 40 | 49 | 49 | 28.7 | 43.8 | 咨询客服 |
| NAG4908 | NAG4908UU | 40 | 62 | 22 | 0.6 | 46 | 56 | 56 | 34.6 | 49.5 | 咨询客服 |
| NAG4909 | NAG4909UU | 45 | 68 | 22 | 0.6 | 51 | 61 | 61 | 36.4 | 54.7 | 咨询客服 |
| NAG4910 | NAG4910UU | 50 | 72 | 22 | 0.6 | 55.5 | 65.5 | 65.5 | 38.2 | 59.9 | 咨询客服 |
| NAG4911 | NAG4911UU | 55 | 80 | 25 | 1 | 61.5 | 72.5 | 72.5 | 48.1 | 77.7 | 咨询客服 |
| NAG4912 | NAG4912UU | 60 | 85 | 25 | 1 | 67 | 77.5 | 77.5 | 50.3 | 84.3 | 咨询客服 |
| NAG4913 | NAG4913UU | 65 | 90 | 25 | 1 | 72 | 83 | 83 | 53.2 | 93 | 咨询客服 |
| NAG4914 | NAG4914UU | 70 | 100 | 30 | 1 | 79 | 91.5 | 91.5 | 77.7 | 139 | 咨询客服 |
