NAU型
| 公称型号(带保持器型) | 主要尺寸(mm) | 额定载荷(KN) | 更多操作 | ||||||||
| 开式 | 密封型 | d | D | B | rs(min) | J | Ew(开式) | Ew(密封型) | Cr | Cor | |
| NAU4900 | ─ | 10 | 22 | 13 | 0.3 | 15.5 | 18.5 | ─ | 6.58 | 6.47 | 咨询客服 |
| NAU4901 | ─ | 12 | 24 | 13 | 0.3 | 17 | 20 | ─ | 6.95 | 7.12 | 咨询客服 |
| NAU4902 | ─ | 15 | 28 | 13 | 0.3 | 21 | 24 | ─ | 7.95 | 9.02 | 咨询客服 |
| NAU4903 | ─ | 17 | 30 | 13 | 0.3 | 22.5 | 25.5 | ─ | 8.24 | 9.67 | 咨询客服 |
| NAU4904 | NAU4904UU | 20 | 37 | 17 | 0.3 | 24 | 31.5 | 31.5 | 10.7 | 11.3 | 咨询客服 |
| NAU4905 | NAU4905UU | 25 | 42 | 17 | 0.3 | 29.5 | 37 | 37 | 11.9 | 13.9 | 咨询客服 |
| NAU4906 | NAU4906UU | 30 | 47 | 17 | 0.3 | 34 | 41.5 | 41.5 | 13 | 16.2 | 咨询客服 |
| NAU4907 | NAU4907UU | 35 | 55 | 20 | 0.6 | 40 | 49 | 49 | 19.5 | 26.3 | 咨询客服 |
| NAU4908 | NAU4908UU | 40 | 62 | 22 | 0.6 | 46 | 56 | 56 | 23.4 | 29.4 | 咨询客服 |
| NAU4909 | NAU4909UU | 45 | 68 | 22 | 0.6 | 51 | 61 | 61 | 24.8 | 32.8 | 咨询客服 |
| NAU4910 | NAU4910UU | 50 | 72 | 22 | 0.6 | 55.5 | 65.5 | 65.5 | 26.2 | 36.2 | 咨询客服 |
| NAU4911 | NAU4911UU | 55 | 80 | 25 | 1 | 61.5 | 72.5 | 72.5 | 33 | 47 | 咨询客服 |
| NAU4912 | NAU4912UU | 60 | 85 | 25 | 1 | 67 | 77.5 | 77.5 | 34.7 | 51.4 | 咨询客服 |
| NAU4913 | NAU4913UU | 65 | 90 | 25 | 1 | 72 | 83 | 83 | 36.9 | 57.1 | 咨询客服 |
| NAU4914 | NAU4914UU | 70 | 100 | 30 | 1 | 79 | 91.5 | 91.5 | 53.7 | 84.6 | 咨询客服 |
