BTW系列主轴轴承
| 公称型号(双向推力) | 主要尺寸(mm) | 额定载荷(KN) | 更多操作 | ||||||||
| BTW系列 | d | D | T | C | r(min) | r1(min) | d1 | D1 | Cr | Cor | |
| BTW35CTDBLP4 | 35 | 62 | 34 | 17 | 1 | 0.3 | 50.8 | 50.2 | 16.8 | 39 | 咨询客服 |
| BTW40CTDBLP4 | 40 | 68 | 36 | 18 | 1 | 0.3 | 56.4 | 55.9 | 19.5 | 46.5 | 咨询客服 |
| BTW45CTDBLP4 | 45 | 75 | 38 | 19 | 1 | 0.3 | 62.5 | 61.9 | 22.1 | 54 | 咨询客服 |
| BTW50CTDBLP4 | 50 | 80 | 38 | 19 | 1 | 0.3 | 67.5 | 66.9 | 22.5 | 60 | 咨询客服 |
| BTW55CTDBLP4 | 55 | 90 | 44 | 22 | 1.1 | 0.6 | 75.2 | 74.4 | 30.2 | 80 | 咨询客服 |
| BTW60CTDBLP4 | 60 | 95 | 44 | 22 | 1.1 | 0.6 | 80.2 | 79.4 | 30.7 | 83 | 咨询客服 |
| BTW65CTDBLP4 | 65 | 100 | 44 | 22 | 1.1 | 0.6 | 85.2 | 84.4 | 31.9 | 90 | 咨询客服 |
| BTW70CTDBLP4 | 70 | 110 | 48 | 24 | 1.1 | 0.6 | 93.5 | 92.5 | 39 | 112 | 咨询客服 |
| BTW75CTDBLP4 | 75 | 115 | 48 | 24 | 1.1 | 0.6 | 98.5 | 97.5 | 39.7 | 116 | 咨询客服 |
| BTW80CTDBLP4 | 80 | 125 | 54 | 27 | 1.1 | 0.6 | 106.2 | 105 | 47.5 | 140 | 咨询客服 |
| BTW85CTDBLP4 | 85 | 130 | 54 | 27 | 1.1 | 0.6 | 112 | 110 | 48.8 | 146 | 咨询客服 |
| BTW90CTDBLP4 | 90 | 140 | 60 | 30 | 1.5 | 0.6 | 119 | 117.5 | 55.9 | 173 | 咨询客服 |
| BTW95CTDBLP4 | 95 | 145 | 60 | 30 | 1.5 | 0.6 | 124 | 122.5 | 57.2 | 180 | 咨询客服 |
| BTW100CTDBLP4 | 100 | 150 | 60 | 30 | 1.5 | 0.6 | 129 | 127.5 | 59.2 | 193 | 咨询客服 |
| BTW105CTDBLP4 | 105 | 160 | 66 | 33 | 2 | 1 | - | - | 85 | 265 | 咨询客服 |
